Pitch Black Thermal

RIX DBH D6 - COMING SOON

RIX DBH D6 - COMING SOON

$5,699.00 USD
$5,899.00 USD $5,699.00 USD
Sale Sold out

HIGH-PERFORMANCE SENSOR

The DBH D6 is equipped with a 640×512 12μm sensor boasting a NETD＜20mK and a 60Hz refresh rate, ensuring hunters always get a clear and smooth image.

COMFORTABLE OPTICAL IMAGING

The DBH D6 feautres a 60mm objective lens with 3x base magnification. The 3-18x magnification range helps users clearly observe targets at longer distances. Digital zoom control that steps in precise 0.1x increments.

2560×2560 HIGH-RESOLUTION CIRCULAR OLED DISPLAY

The circular high-resolution 1.03in OLED screen allows for precise zeroing, maintaining each adjustment at only 3/8" @ 100 yards while providing a highly detailed image.

BALLISTIC CALCULATION IN BOTH DEVICE AND APP

Automatically calculate the aiming position and display it on the device screen based on air temperature, wind speed, ammunition, distance and other information. Using WIFI and RIX+ APP, ballistic parameters can be uploaded or downloaded, so that shots are more precise

8 HOURS OPERATING TIME

Powered by two 18650 batteries that can be inserted in any orientation, makes battery changes in the dark a lot easier.

INTUITIVE DESIGN

The dual side focusing structure with 250° rotation cycle and the quick throw zoom lever make zooming in and out quick and convenient, helping you acquire targets faster. The dual lever return to zero QD mount makes mounting and unmounting quick and easy.

FEATURES FOR HUNTERS

The DBH D6 provides multiple functions that can effectively improve the hunting experience. Boasting an integrated green laser that is easily activated for marking downed game(an industry first). A Built-in 1200-yard Laser Rangefinder and video & photo playback features in the scope.

RECOIL ACTIVATED VIDEO

The DBH D6 provides a recoil detection algorithm, it detects recoil in real-time and records every moment of your action packed hunt.

MORE FEATURES



Built-in MIC

Experience uncompromising audio quality with our carefully selected built-in microphone.


Photo, Video Recording and Display

The DBH D6 features built-in photo & video recording capabilities with 64GB of internal storage. Effortlessly capture remarkable moments, day or night.


1000g Impact Resistance

The DBH D6’s durable design enables it to withstand impacts of up to 1000g, making it an ideal choice for rifles with large calibers such as .375 H&H, 12-gauge, and 9.3×64. It is built to ensure longevity and to remain undamaged even under challenging conditions.


Wi-Fi integration with the RIX+ APP

With the built-in Wi-Fi module, you can establish a seamless connection between the device and your Android or iOS smartphone via the RIX+ app. This powerful combination offers a multitude of advantages, such as wireless software updates and live image streaming directly to your mobile device screen. ​


Picture-in-Picture Function (PIP)

The DBH D6 is also equipped with a PIP (picture-in-picture) function. When enabled, the DBH D6 will display a zeroing frame on the screen. It allows the user to observe the image in the aiming area while maintaining visual control of the entire field of view.

Sensor Specifications
Type
VOx Uncooled



Resolution, pixels
640×512



Pixel Pitch, µm
12



NETD, mK
≤20



Frame Rate, Hz
60



Optical Specifications
Objective Lens，mm
60 F1.0



Optical Zoom, x
3



Field of View, degrees / yd @ 100 yd
7.3°×5.8°



Digital Zoom, x
1 to 6, stepped



Eye Relief, mm
60



Diopter Adjustment, D
-5 to +2



Detection Range, m/yd
3280



Display Specifications
Type
OLED



Resolution, pixels
2560 x 2560



LRF Specification
Type, nm
905



Max Range, yd
1200



Wi-Fi
Wireless Protocol
Wi-Fi



Frequency, GHz
2.4GHz



BT
Frequency, MHz
2402~2480



Video Recorder
Video / Photo Resolution, pixels
1280×1280



Video / Photo Format
.mp4 / .jpg



Built-in Memory, GB
64



Physical Specifications
Degree of Protection, IP code
IP67



Operating Temperature Range, °F
-4 to +122



Weight, lb
2.9



Dimensions, inch
10.3×3.3×3.8



Connections and Compatibilities
Battery Type
18650×2



Capacity, mAh
3800



Operating Time on Battery Pack (at t=72°F), h
8



External Power Supply, V
5V (Type C USB)



Max Recoil Power on Rifled Weapon (Eo), g/Joules
1000g/6000Joules



Compatible Mounts



IP67 waterproof

Engineered with an impressive IP67 waterproof housing, the DBH D6 is fortified against water intrusion, ensuring robust protection. This exceptional waterproofing capability safeguards the internal components, significantly extending its lifespan.

WARRANTY POLICY
DURATION: 5-YEAR
Coverage:

All products from RIX Optics are guaranteed to be free from manufacturing defects or breakage associated with the intended normal use of the product during the periods as stated above from the date of purchase.

Return, Repair or Replacement:
We strive to ensure that your experience with us is effortless and trouble-free. If you purchase through our website you can get a full refund/exchange within 30 days, and if you have any warranty work that needs to be conducted, RIX will cover the shipping costs for the first 60 days after your date of purchase.
